Mooring Whips Installation

Whip base installation:

  • Each mooring whip base or mount should be aligned with the tender’s cleat.
  • The further apart the attachment points, the better.
  • The whips should be perpendicular (90°) to the tender.

Whip Poles:

  • Connect the two whip halves, making sure to align the end of the whip with the cleat.
  • The two halves can be permanently fixed together using an epoxy adhesive if required, although not doing so will enable easy stowage.
  • Insert the whips into the bases
  • Do not be afraid to bend the poles. However, it is important that when under full tension, the tip is never lower than the base.
  • Over bending the pole will actually reduce the tension/performance of the whip and increase the risk of damage.

Lines:

  • When securing the tender, bow and stern, two spring lines must be used.
  • Adjust the lines so they are taught.
  • Prevent the whips from bending sideways.
  • Every effort should be made to keep the whips perpendicular to the cleats on the tender.
  • The breast lines should be at a length that holds the tender a minimum of 1.8 metres from the dock or gunwale.

Warranty:

  • Twelve months warranty is offered, provided that the above guide is followed.
  • Our tender whips are not designed to be used in conditions above Force 4.
  • Therefore, the warranty will not cover any damage incurred during such conditions.
